Bolt Weight Chart in Kg, mm, & PDF – AKBAR FASTENERS PRIVATE LIMITED
Bolt Weight Chart in Kg provides accurate information about bolt weights based on different sizes, diameters, lengths, and material specifications. This chart helps engineers, manufacturers, and industries calculate bolt requirements easily. Akbar Fasteners Private Limited manufactures high-quality bolts according to DIN, ASTM, ISO, and BS standards.
AKBAR FASTENERS PRIVATE LIMITED provides a comprehensive and inclusive Bolt Weight Chart in Kg, mm, and PDF format. The chart includes accurate weight information for a wide range of bolt sizes in both kilograms and millimeters. It helps engineers, manufacturers, and buyers quickly identify the correct bolt specifications for their applications. Save time and improve accuracy when selecting fasteners for industrial and mechanical projects. This is widely important for professionals and industries that require exact measurement and specification of nuts used in various applications and purpose.
Bolt Weight Chart in Kg, mm & PDF
The chart helps users quickly identify the weight and size specifications of various nuts used in industrial and mechanical applications.
| Length | Diameter | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| 1⁄2“ | 5⁄8“ | 3⁄4“ | 7⁄8“ | 1″ | 11⁄8“ | 11⁄4“ | 13⁄8 | 11⁄2 | |
| 1 | 16.5 | 29.4 | 47.0 | – | – | – | – | – | |
| 11⁄4 | 17.8 | 31.3 | 49.6 | 74.4 | 104 | – | – | – | – |
| 11⁄2 | 19.2 | 33.1 | 52.2 | 78 | 109 | 148 | 197 | – | – |
| 13⁄4 | 20.5 | 35.3 | 55.3 | 81.9 | 114 | 154 | 205 | 261 | 333 |
| 2 | 21.9 | 37.4 | 58.4 | 86.1 | 119 | 160 | 212 | 270 | 344 |
| 21⁄4 | 23.3 | 39.8 | 61.6 | 90.3 | 124 | 167 | 220 | 279 | 355 |
| 21⁄2 | 24.7 | 41.7 | 64.7 | 94.6 | 130 | 174 | 229 | 290 | 366 |
| 23⁄4 | 26.1 | 43.9 | 67.8 | 98.8 | 135 | 181 | 237 | 300 | 379 |
| 3 | 27.4 | 46.1 | 70.9 | 103 | 141 | 188 | 246 | 310 | 391 |
| 31⁄4 | 28.8 | 48.2 | 74 | 107 | 146 | 195 | 255 | 321 | 403 |
| 31⁄2 | 30.2 | 50.4 | 77.1 | 111 | 151 | 202 | 263 | 332 | 416 |
| 33⁄4 | 31.6 | 52.5 | 80.2 | 116 | 157 | 209 | 272 | 342 | 428 |
| 4 | 33 | 54.7 | 83.3 | 120 | 162 | 216 | 280 | 353 | 441 |
| 41⁄4 | 34.3 | 56.9 | 86.4 | 124 | 168 | 223 | 289 | 363 | 453 |
| 41⁄2 | 35.7 | 59 | 89.5 | 128 | 173 | 230 | 298 | 374 | 465 |
| 43⁄4 | 37.1 | 61.2 | 92.7 | 133 | 179 | 237 | 306 | 384 | 478 |
| 5 | 38.5 | 63.3 | 95.8 | 137 | 184 | 244 | 315 | 395 | 490 |
| 51⁄4 | 39.9 | 65.5 | 98.9 | 141 | 190 | 251 | 324 | 405 | 503 |
| 51⁄2 | 41.2 | 67.7 | 102 | 146 | 196 | 258 | 332 | 416 | 515 |
| 53⁄4 | 42.6 | 69.8 | 105 | 150 | 201 | 265 | 341 | 426 | 527 |
| 6 | 44 | 71.9 | 108 | 154 | 207 | 272 | 349 | 437 | 540 |
| 61⁄4 | – | 74.1 | 111 | 158 | 212 | 279 | 358 | 447 | 552 |
| 61⁄2 | – | 76.3 | 114 | 163 | 218 | 286 | 367 | 458 | 565 |
| 63⁄4 | – | 78.5 | 118 | 167 | 223 | 293 | 375 | 468 | 577 |
| 7 | – | 80.6 | 121 | 171 | 229 | 300 | 384 | 479 | 589 |
| 71⁄4 | – | 82.8 | 124 | 175 | 234 | 307 | 392 | 489 | 602 |
| 71⁄2 | – | 84.9 | 127 | 179 | 240 | 314 | 401 | 500 | 614 |
| 73⁄4 | – | 87.1 | 130 | 183 | 246 | 321 | 410 | 510 | 626 |
| 8 | – | 89.2 | 133 | 187 | 251 | 328 | 418 | 521 | 639 |
| 81⁄4 | – | – | – | 192 | 257 | 335 | 427 | 531 | 651 |
| 81⁄2 | – | – | – | 196 | 262 | 342 | 435 | 542 | 664 |
| 83⁄4 | – | – | – | – | – | – | 444 | 552 | 676 |
| 9 | – | – | – | – | – | – | 453 | 563 | 689 |
| Per inch Adder | 5.5 | 8.6 | 12.4 | 16.9 | 22.1 | 28 | 34.4 | 42.5 | 49.7 |
| F436 Round Washers | 2.1 | 3.6 | 4.8 | 7 | 9.4 | 11.3 | 13.8 | 16.8 | 20 |
Bolt Weight Chart in Kg helps engineers, manufacturers, and industries accurately determine bolt weights based on size, diameter, length, and material specifications. Akbar Fasteners Private Limited provides high-quality bolts manufactured according to DIN, ASTM, ISO, and BS standards. Screw Weight Chart in Kg By using the Bolt Weight Chart in Kg, customers can easily plan material requirements, reduce wastage, and select the right bolts for various industrial applications. Screw Weight Chart in Kg
