Akbar Fasteners Private Limited provides comprehensive an inclusive Anchor Bolts Weight Chart in Kg, mm, & PDF, which provides the weights in a range of sizes in both Kg and mm. This is widely important for professionals and industries that require exact measurement and specification of nuts used in various applications and purpose
Anchor Bolts Weight Chart, Dimensional Chart in Kg, mm & PDF
This detailed chart provides essential information on the weight and size of various nuts used in industrial and mechanical applications..
| Bolt | inside Diam id | Outside Diam od | Thickness | |||
|---|---|---|---|---|---|---|
| Diam mm | Min mm | Max mm | Min mm | Max mm | Min mm | Max mm |
| M8 | 9.0 | 9.36 | 19.7 | 21.0 | 1.79 | 2.21 |
| M10 | 11.0 | 11.36 | 22.7 | 24.0 | 1.79 | 2.21 |
| M12 | 14.0 | 14.43 | 26.7 | 28.0 | 2.29 | 2.71 |
| M14 | 16.0 | 16.43 | 28.7 | 30.0 | 2.29 | 2.71 |
| M16 | 18.0 | 18.43 | 32.4 | 34.0 | 2.77 | 3.23 |
| M18 | 20.0 | 20.43 | 35.4 | 37.0 | 2.77 | 3.23 |
| M20 | 22.0 | 22.52 | 37.4 | 39.0 | 2.77 | 3.23 |
| M22 | 24.0 | 24.52 | 42.4 | 44.0 | 2.77 | 3.23 |
| M24 | 26.0 | 26.52 | 48.4 | 50.0 | 3.75 | 4.25 |
| M27 | 30.0 | 30.52 | 54.1 | 56.0 | 3.75 | 4.25 |
| M30 | 33.0 | 33.52 | 58.1 | 60.0 | 4.73 | 5.27 |
| M13 | 36.0 | 36.62 | 64.1 | 66.0 | 4.73 | 5.27 |
| M36 | 39.0 | 39.62 | 70.1 | 72.0 | 5.71 | 6.29 |
| M39 | 42.0 | 42.62 | 76.1 | 78.0 | 5.71 | 6.29 |
| M42 | 45.0 | 45.62 | 81.8 | 84.0 | 6.71 | 7.29 |
| M4B | 52.0 | 52.62 | 93.8 | 96.0 | 7.50 | 8.50 |
| MS6 | 62.0 | 62.74 | 109.8 | 112.0 | 8.50 | 9.50 |
| M64 | 70.0 | 70.74 | 125.5 | 128.0 | 8.50 | 9.50 |
